AL1921 IO-Link master with EtherNet/IP interface
116
Set fail-safe data pattern (0x30)
The command sets the behaviour of the outputs when the EtherNet/IP connection and the
corresponding fail-safe values are interrupted.
Command response
Byte
(Offset)
Bit
7 6 5 4 3 2 1 0
4 Port No. (LSB)
5 Port No. (MSB)
6 reserved
7 reserved
8 reserved
9 reserved
10 Handshake 0x30
11 Result
12 Fail-safe mode
13 reserved
… …
45 reserved
• Handshake Validity of the IO-Link response data 1BIT • 0x0: data invalid
• 0x1: data valid
• Result Status of the command processing 1BYTE • 0x00: OK
• 0x0F: OK, data user read > 32 bytes
• 0xFF: Error
• Fail-safe mode Fail-safe mode for the outputs of the IO-
Link ports in case of an interruption of the
EtherNet/IP connection
1BYTE • 0x00: No Fail-safe
• 0x01: Fail-safe - Reset Value
• 0x02: Fail-safe - Old Value
• 0x03: Fail-safe - Pattern
