AL1921 IO-Link master with EtherNet/IP interface
114
Set validation ID / data storage (0x20)
The command sets the behaviour of the IO-Link master when connecting a new IO-Link device to an
IO-Link port of the device.
Command request
Byte
(offset)
Bit
7 6 5 4 3 2 1 0
4 Port No. (LSB)
5 Port No. (MSB)
6 reserved
7 reserved
8 reserved
9 reserved
10 Trigger 0x20
11 Validation ID
12 reserved
… …
45 reserved
Legend:
• Port No. IO-Link Port
Port No. 0x1234
• Port No. (MSB): 0x12
• Port No. (LSB): 0x34
1WORD • 0x0001: Port 1
• 0x0002: Port 2
• 0x0003: Port 3
• 0x0004: Port 4
• 0x0005: Port 5
• 0x0006: Port 6
• 0x0007: Port 7
• 0x0008: Port 8
• Trigger Control of the command execution 1BIT • 0x0: no action
• 0x1: Execute command
• Validation ID Validation type and data storage behaviour
of the port
1BYTE • 0x00: No check
• 0x01: Type compatible V1.0 device
• 0x02: Type compatible V1.1 device
• 0x03: Type compatible V1.1 device with
Backup + Restore
• 0x04: Type compatible V1.1 device with
Restore
