IO-Link master with EtherNet/IP interface AL1921
103
Mapping: Port Qualifier Information (PQI)
Byte
(Offset)
Bit
7 6 5 4 3 2 1 0
n Diagnosis
present
Wrong
Length PD-
out
Wrong
Length
PDin
Wrong Cy-
cle Time
Wrong VID /
DID
Invalid Data Dev Not
Con
IOL mode
n+1 reserved
Legend:
• IOL mode Operating mode of the port (pin 4) 1 bits • 0x0: Other
• 0x1: IO-Link
• Dev Not Con Connection status to IO-Link device on the
port
1 bits • 0x0: connected
• 0x1: Device is not connected
• Invalid Data Status of the process data 1 bits • 0x0: valid
• 0x1: invalid
• Wrong VID / DID Match between configured and recognised
Vendor ID / Device ID
1 bits • 0x0: OK
• 0x1: no match
• Wrong Cycle Time Conformity of configured and detected cy-
cle time
1 bits • 0x0: OK
• 0x1: no match
• Wrong Length
PDin
Match between configured and detected
process data length (inputs)
1 bits • 0x0: OK
• 0x1: configured process data length too
small
• Wrong Length
PDout
Match between configured and detected
process data length (outputs)
1 bits • 0x0: OK
• 0x1: configured process data length too
small
• Diagnosis present Indication of new IO-Link events (Coming
Event, Single Shot Event)
• Coming Events disappears when the
corresponding Disappearing Event
occurs
• Single Shot Events disappear
automatically
1 bits • 0x0: no IO-Link event
• 0x1: new IO-Link event detected
Mapping: IO-Link information + events
Byte (Off-
set)
Bit
7 6 5 4 3 2 1 0
n Vendor ID (LSB)
n+1 Vendor ID (MSB)
n+2 Device ID (LSB)
n+3 Device ID
n+4 Device ID (MSB)
n+5 reserved
n+6 Event 1: Mode Event 1: Type Event 1: Src Event 1: Instance
n+7 Event Code 1 (LSB)
n+8 Event Code 1 (MSB)
n+9 Event 2: Mode Event 2: Type Event 2: Src Event 2: Instance
n+10 Event 2 (LSB)
n+11 Event 2 (MSB)
n+12 Event 3: Mode Event 3: Type Event 3: Src Event 3: Instance
n+13 Event 3 (LSB)
n+14 Event 3 (MSB)
