SolutionBlock IO-Link master AL1591
41
Parameter Description Value range Access
iolinkmaster/port[x]/porte-
vent
Port event at port x (x: X1...X8)
Structure: 0xYYZZ00
• 0xYY: Device Status - Status of the
IO-Link devices
• 0xZZ: Connection Status - Status of
the connection
Device status:
• 0x00: No IO-Link device connected
• 0x40: Wrong IO-Link device connected
• 0x80: IO-Link device connected and in
PREOPERATE state
• 0xFF: IO-Link device connected and in
OPERATE state
Connection Status:
• 0x00: Port deactivated
• 0x01: Port activated, but no device
connected
• 0x02: Port activated and in “IO-Link”
operating mode
• 0x03: Port activated and in “DI”
operating mode
• 0x04: Port enabled and in “DO”
operating mode
• 0x1B: Repetitions detected
• 0x1E: Short circuit detected at pin 4
• 0x42: Wrong revision of the IO-Link
device
• 0x43: Wrong vendor ID (V1.1
Revision)
• 0x44: Wrong device ID (V1.1 Revision)
• 0x45: Wrong vendor ID (V1.0
Revision)
• 0x46: Wrong device ID (V1.0 Revision)
• 0x48: Wrong cycle time
ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
ü The dashboard area is displayed.
u Select the [Dashboard] tab.
w The view shows the current port events of the device’s ports.
9.1.7 Device information
The [Info] menu provides access to the identification information of the device.
9.1.7.1 Reading identification information
Available information:
Name Description Value range Access
[Order number] Article number AL1591 ro
1
[Product code] Product designation IO-LINK MASTER SOL MP 8P IP69K ro
1
[Production date] Production time (date, time) e.g. "15.07.2024, 15:13:16.36" ro
1
[Vendor] Vendor ifm electronic gmbh ro
1
[SW-Revision] Firmware version E.g. 1.0.3.6 ro
1
[HW-Verison] Hardware version E.g. 1.2.1.1 ro
1
[HW-Revision] Hardware version E.g. AA ro
1
[Serial number] Serial number E.g. 000194610104 ro
1
