AL1431 IO-Link master with EtherCAT interface
74
11.1.3.6 Information Area (0x9000 - 0x9FFF)
Index Subindex Name Possible values
Data type /
access
0x9000 -- Port 1: Port Mode Status
• 0x04 Device ID 0x000000…0xFFFFFF UINT32 / ro
• 0x05 Vendor ID 0x0000…0xFFFF UINT32 / ro
• 0x20 IO-Link revision • 0x10: IO-Link Revision 1.0
• 0x11: IO-Link Revision 1.1
UINT8 / ro
• 0x21 Frame Capability UINT8 / ro
• 0x22 Cycle Time • 0x0000 0000: Best possible
• 0x0000 0001: 1 µs
…
• 0x0002 06C0: 132800 µs
UINT8 / ro
• 0x24 PD In Length • 0x00: 0 byte
• 0x01: 4 bytes
• 0x02: 8 bytes
• 0x03: 16 bytes
• 0x04: 32 bytes
UINT8 / ro
• 0x25 PD Out Length • 0x00: 0 byte
• 0x01: 4 bytes
• 0x02: 8 bytes
• 0x03: 16 bytes
• 0x04: 32 bytes
UINT8 / ro
0x9001 Port 1: Serial number IO-Link Device STRING / ro
0x9008 Port 1: Specific IO information
• 0x01 Current UA (Pin 2/5) • 0x0000: 0mA
…
• 0x07D0: 2000mA
UINT16 / ro
• 0x02 Current US (Pin 1/3) • 0x0000: 0mA
…
• 0x07D0: 2000mA
UINT16 / ro
0x9010
Port 2: Port Mode (structure: Ò Index 0x9000)
0x9011 Port 2: Serial number IO-Link Device STRING / ro
0x9018
Port 2: Specific IO information (structure: Ò Index 0x9008)
0x9020
Port 3: Port Mode (structure: Ò Index 0x9000)
0x9021 Port 3: Serial number IO-Link Device STRING / ro
0x9028
Port 3: Specific IO information (structure: Ò Index 0x9008)
0x9030
Port 4: Port Mode (structure: Ò Index 0x9000)
0x9031 Port 4: Serial number IO-Link Device STRING / ro
0x9038
Port 4: Specific IO information (structure: Ò Index 0x9008)
