AL1431 IO-Link master with EtherCAT interface
72
11.1.3.5 Configuration Area (0x8000 - 0x8FFF)
Index Subindex Name Possible values
Data type /
access
0x8000 Port 1: Port Configuration
• 0x04 Device ID 0x000000…0xFFFFFF UINT32 / rw
• 0x05 Vendor ID 0x0000…0xFFFF UINT32 / rw
• 0x20 IO-Link revision • 0x10: IO-Link Revision 1.0
• 0x11: IO-Link Revision 1.1
UINT8 / rw
• 0x22 Cycle Time • 0x0000 0000: Best possible (Default)
• 0x0000 0001: 1 µs
…
• 0x0002 06C0: 132800 µs
UINT32 / rw
• 0x24 Process Data In Length • 0x00: 0 byte
• 0x01: 4 Bytes (Default)
• 0x02: 8 bytes
• 0x03: 16 bytes
• 0x04: 32 bytes
UINT8 / rw
• 0x25 Process Data Out Length • 0x00: 0 byte
• 0x01: 4 Bytes (Default)
• 0x02: 8 bytes
• 0x03: 16 bytes
• 0x04: 32 bytes
UINT8 / rw
• 0x28 Master Control • 0x0000: Deactivated
• 0x0001: Digital Input
• 0x0002: Digital Output
• 0x0003: IO-Link (Default)
UINT16 / rw
0x8008 Port 1: Vendor Specific Port Configuration
• 0x01 Validation ID • 0x00: No check (Default)
• 0x01: V1.0 Device, no Datastorage
• 0x02: V1.1 Device, no Datastorage
• 0x03: V1.1 Device, Backup + Restore
• 0x04: V1.1 Device, Restore
UINT8 / rw
• 0x02 Reconfigure • 0x00: No action (Default)
• 0xFF: Activate configuration
UINT8 / rw
• 0x03 Byte Swap • 0x00: No action (Default)
• 0x01: Byte swap
UINT8 / rw
• 0x04 Mode UA • 0x0000: UA = OFF - IO-Link Port Class A
• 0x0001: UA = ON - IO-Link Port Class B
(Default)
• 0x0002: Digital Output (DO)
UINT16 / rw
• 0x05 Current Limit UA • 0x0000: 0mA
…
• 0x07D0: 2000mA (default)
UINT16 / rw
• 0x06 Current Limit US • 0x0000: 0mA
…
• 0x01C2: 450mA
…
• 0x07D0: 2000mA (default)
UINT16 / rw
0x8010
Port 2: Port Configuration (structure: Ò Index 0x8000)
0x8018
Port 2: Vendor Specific Port Configuration (structure: Ò Index 0x8008)
0x8020
Port 3: Port Configuration (structure: Ò Index 0x8000)
0x8028
Port 3: Vendor Specific Port Configuration (structure: Ò Index 0x8008)
