AL1431 IO-Link master with EtherCAT interface
64
11.1.3 Object directory
11.1.3.1 Communication Area (0x1000 - 0x1FFF)
Index Subindex Name Possible values
Data type /
access
0x1000 -- Device Type • 0x184C1389: Modular Device Profile (MDP) UINT32 / ro
0x1008 -- Manufacturer Device Name "AL1431 " STRING / ro
0x1009 -- Manufacturer Hardware Version STRING / ro
0x100A -- Manufacturer Software Version STRING / ro
0x100B -- Bootloader Version STRING / ro
0x1018 -- Identity Object
• 0x1 Vendor ID 0x622: ifm electronic UINT32 / ro
• 0x2 Product Code "AL1431 " UINT32 / ro
• 0x3 Revision Number e.g., “AA” UINT32 / ro
• 0x4 Serial number e.g., “000045632787” UINT32 / ro
0x10F3 Diagnosis History
• 0x01 Maximum Messages • 0x00: 0 Messages
…
• 0x20: 32 Messages
UINT8 / ro
• 0x02 Newest Message • 0x01: Message 1
…
• 0x20: Message 32
UINT8 / ro
• 0x03 Newest Ack. Message Override Mode:
• 0x00: Reading: When the message queue will
be overwritten, the slave shall set subindex
0x03 to 0
• 0x01…0x05: Writing: The slave shall return
SDO-Abort with codes 0x06090030 (value
range of parameter exceeded) or 0x0609003
• 0x06…0x46: Writing: Subindex 0x03 = Written
value without checking
• 0x47…0xFF: Writing: SDO-Abort with codes
0x06090030 or 0x06090031(value of parameter
written too high)
Acknowledge Mode:
• 0x00:
– Read: No messages have been
acknowledged so far
– Writing: All acknowledged messages will be
deleted.
• 0x01…0x05: Writing: The slave shall return
SDO-Abort with codes 0x06090030 (value
range of parameter exceeded) or 0x06090032
• 0x06…0x26:
– Read: SubIndex of latest acknowledged
diagnosis message
– Writing: Messages are acknowledged
• 0x27…0xFF: Writing: SDO-Abort with codes
0x06090030 or 0x06090031(value of parameter
written too high)
UINT8 / rw
