IO-Link master with EtherCAT interface AL1431
61
11.1.2.2 IO-Link Ch.2
Slot Description Available modules
Length
[bytes]
2 Port 2: Port configuration
(pin4)
• Deactivated: Port disabled 0
• Digital_IN: “Digital input” operating mode 1/0
• Digital_OUT: “Digital output” operating mode 0/1
• IOL_In_4Byte: “IO-Link” operating mode – 4 byte input data 4/0
• IOL_In_8Byte: “IO-Link” operating mode – 8 byte input data 8/0
• IOL_In_16Byte: “IO-Link” operating mode – 16 byte input data 16/0
• IOL_In_32Byte: “IO-Link” operating mode – 32 byte input data 32/0
• IOL_Out_4Byte: “IO-Link” operating mode – 4 byte output data 0/4
• IOL_Out_8Byte: “IO-Link” operating mode – 8 byte output data 0/8
• IOL_Out_16Byte: “IO-Link” operating mode – 16 byte output data 0/16
• IOL_Out_32Byte: “IO-Link” operating mode – 32 byte output data 0/32
• IOL_4/4_I/O-Bytes: “IO-Link” operating mode – 4-byte input data /
4-byte output data (default)
4/4
• IOL_8/8_I/O-Bytes: “IO-Link” operating mode – 8 byte input data /
8 byte output data
8/8
• IOL_4/16_I/O-Bytes: “IO-Link” operating mode – 4 byte input
data / 16 byte output data
4/16
• IOL_16/4_I/O-Bytes: “IO-Link” operating mode – 16 byte input
data / 4 byte output data
16/4
• IOL_16/16_I/O-Bytes: “IO-Link” operating mode – 16 byte input
data / 16 byte output data
16/16
• IOL_32/32_I/O-Bytes: “IO-Link” operating mode – 32 byte input
data / 32 byte output data
32/32
