AL1431 IO-Link master with EtherCAT interface
40
9.2.4 Accessing the process data
The [Processdata] menu page provides access to the process data of the device.
Requirements:
ü IoT Core Visualizer has been started.
u Select the [Processdata] menu.
w The menu page shows the substructures of the device description that contains the process data.
w The current process values are displayed.
u Optional: In the header, activate the [Polling] option and set the polling interval.
w The process values will be refreshed with the set interval.
u Optional: Click on next to an element to manually refresh the process value.
9.2.4.1 Reading the status and diagnostic data of the device
Available information:
Name Description Value range Access
[temperature] Temperature of the device (value in °C) • -30: -30°C
…
• 80: 80°C
ro
1
[voltage] Current voltage of the device supply US
(value in millivolts)
• 0: 0mV
…
• 4000: 4000mV
ro
1
[supervisionstatus] Status of the voltage supply US • ok: No error
• fault: Error
ro
1
[current_ua] Present current intensity of the device
supply UA (value in milliamps)
• 0: 0mA
…
• 4000: 4000mA
ro
1
[supervisionstatus_ua] Status of the voltage supply UA • ok: No error
• fault: Error
ro
1
