AL1431 IO-Link master with EtherCAT interface
38
Name Description Value range Access
[validation_datastor-
age_mode]
Validation of the connected IO-
Link devices and automatic re-
store of parameter sets of the IO-
Link device
• No check and clear
• Type compatible V1.0 device
• Type compatible V1.1 device
• Type compatible V1.1 device with Backup
+ Restore
Type compatible V1.1 device with Restore
rw
1
2
[validation_vendorid] Vendor ID of the IO-Link device to
be validated against
e.g., 310: ifm electronic gmbh rw
1
2
[validation_deviceid] Device ID of the IO-Link device to
be validated against
e.g., 1129: TCC501 (ifm temperature sensor) rw
1
2
1
Read and write
2
Parameter only available if operating mode pin 4 (US) = IO-Link and IO-Link device is connected to the port
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [Iolinkmaster] > [port[x]] submenu (x: 1…4).
u Set the parameters for device validation and backup / restore of parameter values.
u Optional: Enter the vendor ID and device ID.
u Click on to save the changes to the device.
w Device validation and backup / restore of parameter values have been configured.
9.2.3.9 Setting data transmission to the monitoring software
Available parameters:
Name Description Value range Access
[senddatatosmob] Enable / Disable the transmission of
process data of the port to the monitor-
ing software
• disabled: Process data not transmitted
• enabled: Process data transmitted
rw
1
1
Read and write
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
ü Interface to the monitoring software has been configured.
u Select the [Iolinkmaster] > [port[x]] submenu (x: 1…4).
w The menu page shows the current settings.
u Set the parameters.
u Click on to save the changes to the device.
w Data transmission to the monitoring software has been set.
9.2.3.10 Reading the firmware version
Available information:
Name Description Value range Access
[version] Firmware version 4.7.0.3 (EtherCAT Slave) ro
1
1
Read only
Requirements:
