AL1431 IO-Link master with EtherCAT interface
26
Name Description Value range Access
Validation / Data Storage Validation of the connected IO-Link de-
vices and automatic restore of parame-
ter sets of the IO-Link device
• No check and clear
• Type compatible V1.0 device
• Type compatible V1.1 device
• Type compatible V1.1 device with
Backup + Restore
• Type compatible V1.1 device with
Restore
rw
1
2
Vendor ID Vendor ID of the IO-Link device to be
validated against
e.g., 310: ifm electronic gmbh rw
1
2
Device ID Device ID of the IO-Link device to be
validated against
e.g., 1129: TCC501 (ifm temperature
sensor)
rw
1
2
1
Read and write
2
Parameter only available if operating mode pin 4 (US) = IO-Link and IO-Link device is connected to the port
To configure the device validation and the backup / restore of parameter values:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
ü The detailed view of the device is active.
ü Operating mode of pin 4 of the port is “IO-Link”.
u Select the [Port x] > [IO-Link] menu (x = 1…4).
w The menu page shows the current settings.
u Set the parameters for device validation and backup / restore of parameter values.
u Optional: Enter the vendor ID and device ID.
u Save the changes on the device.
w Device validation and backup / restore of parameter values have been configured.
9.1.8 Ports: Setting the operating mode pin 2 (UA)
Pin 2 of ports 1…4 supports the following operating modes:
• Off: Pin 2 is disconnected from the power supply; Port operates as IO-Link port class A
• On: Voltage UA is connected at pin 2; Port operates as IO-Link port class B
• Digital output (DO): A binary output signal is available at pin 2; Port operates as a digital switching
output
Available parameters:
Name Description Value range Access
[Mode Pin2 UA] Operating mode of pin 2 of the port • Off (IO-Link Type A Supply): IO-Link Port
Class A
• On (IO-Link Type B Supply): IO-Link Port
Class B
• Digital Output: Digital switching output
rw
1
1
Read and write
To set the operating mode of pin 2 (UA) of a port:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
u Select the [Port x] (x = 1…4) menu.
w The menu page shows the current settings.
