AL1431 IO-Link master with EtherCAT interface
10
• Status and error indication of the IO-Link ports (class B)
4.4 EtherCAT
• Device profile: Module device profile (EtherCAT slave)
• Supported protocols:
– AoE (ADS over EtherCAT)
– CoE (CANopen over EtherCAT)
– EoE (Ethernet over EtherCAT)
– File Access over EtherCAT (FoE)
• Device description: ESI file
4.5 ifm IoT Core
Access to the functions of ifm IoT Core is only possible if the Ethernet over EtherCAT (EoE)
protocol is activated and configured on the EtherCAT master and the EtherCAT slave.
u Observe the notes: Using Ethernet over EtherCAT (EoE) (Ò/46)
• Mapping of the data, events and services of the device to an object model (ifm IoT Core)
• Integration of the device in IIoT applications
• Access to the ifm IoT Core:
– Browser-based interface (IoT Core Visualizer)
• Supported protocols: HTTP, TCP, JSON
4.6 Voltage output
The device has a voltage output to supply an additional device. This makes it possible to supply
several devices with one voltage source (daisy chain).
