IO-Link master with EtherCAT interface AL1430
41
Name Description Value range Access
[current] Present current intensity of the device
supply US (value in milliamps)
• 0: 0mA
…
• 4000: 4000mA
ro
1
[voltage_ua] Current voltage of the device supply UA
(value in millivolts)
• 0: 0mV
…
• 4000: 4000mV
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [Processdatamaster] submenu.
w Menu page shows the status and diagnostic information of the device.
9.2.4.2 Setting the counter value
Available parameters:
Name Description Value range Access
[counter] Value of the counter x (x: 1…2) rw
1
1
Read and write
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [Timer[x]] submenu (x: 1…2).
w The menu page shows the current settings.
u Enter the counter value.
u Click on to save the changes to the device.
w The new counter value is active.
9.2.4.3 Reading the status and diagnostic data of the port
Available parameters:
Name Description Value range Access
[current_us] Present current intensity of the volt-
age supply US (value in milliamps)
• 0: 0mA
…
• 2000: 2000mA
ro
1
[current_ua] Present current intensity of the volt-
age supply UA (value in milliamps)
• 0: 0mA
…
• 2000: 2000mA
ro
1
[status] Status of the supply voltages US and
UA
• ok: No error
• fault us: Error in US
• fault ua: Error in UA
• fault us and ua: Error in US and UA
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
