IO-Link master with EtherCAT interface AL1430
27
u Set the operating mode.
u Write the changed values to the device.
w Operating mode of pin 2 (UA) of the port has been set.
9.1.9 Ports: Restricting current intensity
The following electrical properties can be set for ports X1...X4:
• Max. current intensity of the supply voltage US (pin 1 and pin 4)
• Max. current intensity of the supply voltage UA (pin 2)
Available parameters:
Name Description Value range Access
[Current Limit Pin2 UA] Max. current intensity of the supply
voltage UA on the port (value in milli-
amps)
• 0: 0mA (default)
…
• 2000: 2000mA
rw
1
[Current Limit Pin1 + Pin4 US] Max. current intensity of the supply
voltage US on the port (value in milli-
amps)
• 0: 0mA
…
• 450: 450mA (default)
…
• 2000: 2000mA
rw
1
1
Read and write
To restrict the current intensity of the ports:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
u Select the [Port x] (x = 1…4) menu.
w The menu page shows the current settings.
u Set the parameters.
u Write the changed values to the device.
w The output current intensities of the port are restricted.
9.1.10 Ports: Setting data transmission to the monitoring software
Available parameters:
Name Description Value range Access
Transmission to moneo, LR
Agent or SMARTOBSERVER
Enable / Disable the transmis-
sion of process data of the port
to the monitoring software
• Disabled: Process data is not transmitted
• Enabled: Process data is transmitted
rw
1
1
Read and write
To set the data transmission:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
ü The detailed view of the device is active.
ü Interface to the monitoring software has been configured.
u Select the [Port x] (x = 1…4) menu.
w The menu page shows the current settings.
