AL1327 IO-Link master with EtherNet/IP interface
94
• Wrong Length
PDout
Match between configured and detected
process data length (outputs)
1 bits • 0x0: OK
• 0x1: configured process data length too
small
• Diagnosis present Indication of new IO-Link events (Coming
Event, Single Shot Event)
• Coming Events disappears when the
corresponding Disappearing Event
occurs
• Single Shot Events disappear
automatically
1 bits • 0x0: no IO-Link event
• 0x1: new IO-Link event detected
Mapping: IO-Link information + events
Byte (Off-
set)
Bit
7 6 5 4 3 2 1 0
n Vendor ID (LSB)
n+1 Vendor ID (MSB)
n+2 Device ID (LSB)
n+3 Device ID
n+4 Device ID (MSB)
n+5 reserved
n+6 Event 1: Mode Event 1: Type Event 1: Src Event 1: Instance
n+7 Event Code 1 (LSB)
n+8 Event Code 1 (MSB)
n+9 Event 2: Mode Event 2: Type Event 2: Src Event 2: Instance
n+10 Event 2 (LSB)
n+11 Event 2 (MSB)
n+12 Event 3: Mode Event 3: Type Event 3: Src Event 3: Instance
n+13 Event 3 (LSB)
n+14 Event 3 (MSB)
n+15 reserved
Legend:
• VID Vendor ID of the connected IO-Link
device
VID = 0x1234
• DID (MSB): 0x12
• DID (LSB): 0x34
2BYTE 0x0000...0x7FFF
• DID Device ID of the connected IO-Link
device
DID = 0x123456
• DID (MSB): 0x12
• DID: 0x34
• DID (LSB): 0x56
3BYTE 0x000000...0xFFFFFF
• Event m: Mode Mode Mode of the event 2BIT • 0x0: reserved
• 0x1: One-time event
• 0x2: Event has disappeared
• 0x3: Event has appeared
• Event m: Type Type: category of the event 2BIT • 0x0: reserved
• 0x1: Notification
• 0x2: Warning
• 0x3: Error
