IO-Link master with EtherNet/IP interface AL1327
91
11.2.2.2 Input Assembly (Instance 101)
Byte (Off-
set)
Bit
7 6 5 4 3 2 1 0
0…1
Digital Input (Ò Mapping: Digital Input/93)
2…3
Status Information (Ò Mapping: Status Information/93)
4…45
Acyclic Command Channel: Response (Ò Response channel/100)
46…47
Port X01: Mapping: Port Qualifier Information (PQI) (Ò/93)
48…49
Port X02: Mapping: Port Qualifier Information (PQI) (Ò/93)
50…51
Port X03: Mapping: Port Qualifier Information (PQI) (Ò/93)
52…55
Port X04: Mapping: Port Qualifier Information (PQI) (Ò/93)
54…53
Port X05: Mapping: Port Qualifier Information (PQI) (Ò/93)
56…57
Port X06: Mapping: Port Qualifier Information (PQI) (Ò/93)
58…59
Port X07: Mapping: Port Qualifier Information (PQI) (Ò/93)
60…61
Port X08: Mapping: Port Qualifier Information (PQI) (Ò/93)
62 Port X01: Input data IO-Link (n bytes)
1
62+n Port X02: Input data IO-Link (n bytes)
1
62+2n Port X03: Input data IO-Link (n bytes)
1
62+3n Port X04: Input data IO-Link (n bytes)
1
62+4n Port X05: Input data IO-Link (n bytes)
1
62+5n Port X06: Input data IO-Link (n bytes)
1
62+6n Port X07: Input data IO-Link (n bytes)
1
62+7n Port X08: Input data IO-Link (n bytes)
1
1
n: {2, 4, 8, 16, 32}; n is determined by the parameter [Port Process Data Size] in the configuration assembly (Ò
Configuration Assembly (Instance 199)/87)
