AL1327 IO-Link master with EtherNet/IP interface
84
11.1.3.20 Service: start_stream_set
Name: start_stream_set
Description: The service starts the sequential transmission of several data fragments.
Request (“data” field):
Parameter
Mandatory
field
Data type Description
size Mandatory STRING Overall length of the data to be transmitted (number of bytes)
Response (“data” field): none
11.1.3.21 Service: stop
Name: stop
Description: The service stops a function (e.g. connection, timer).
Request (“data” field): none
Response (“data” field): none
11.1.3.22 Service: stream_set
Name: stream_set
Description: The service transfers a data segment.
Request (“data” field):
Parameter
Mandatory
field
Data type Description
value Mandatory BIN
(BASE64)
Segment of the binary data (BASE64-encoded)
Response (“data” field): none
11.1.3.23 Service: subscribe
Name: subscribe
Description: The service creates a notification.
Request ("data"field):
Parameter
Mandatory
field
Data type Description
callback Mandatory STRING Destination address for notifications; URL formats:
• JSON: http://ipaddress:port/path
• JSON: ws:///path
• JSON: mqtt://ipadress:port/topic
• CSV: tcp://ipaddress:port/path
datatosend Mandatory ARRAY OF
STRINGS
List with URLs of the data elements; URLs are comma-separated; ele-
ments must support the getdata service
codec Optional STRING Format of the returned data
• json: JSON formatted
• csv: CSV with standard separator (,)
• csv0: CSV formatted with comma separator (,)
• csv1: CSV formatted with semicolon separator (;)
