AL1327 IO-Link master with EtherNet/IP interface
78
11.1.3 Services
11.1.3.1 Service: factoryreset
Name: factoryreset
Description: The service sets the parameters of the device to the factory settings.
Request (“data” field): none
Response (“data” field): none
11.1.3.2 Service: getblobdata
Name: getblobdata
Description: The service reads a Binary Large Object (blob).
Request (“data” field):
Parameter
Mandatory
field
Data type Description
Pos Mandatory NUMBER Byte position
length Mandatory NUMBER Size of the object (number of bytes)
Response (“data” field):
Parameter
Mandatory
field
Data type Description
data Mandatory STRING Data to be decoded (BASE64-encoded)
crc Optional HEX STRING CRC of the data after decoding
md5 Optional HEX STRING MD5 checksum of the data after decoding
11.1.3.3 Service: getdata
Name: getdata
Description: The service reads the value of a data point and provides it.
Request (“data” field): none
Response (“data” field):
Parameter
Mandatory
field
Data type Description
value Mandatory STRING Value of the data point
11.1.3.4 Service: getdatamulti
Name: getdatamulti
Description: The service sequentially reads the values of multiple data points and outputs them. The
value and a diagnostic code are output for each data point.
Request (“data” field):
Parameter
Mandatory
field
Data type Description
datatosend Mandatory ARRAY OF
STRINGS
List of data points to be requested; data points must support the getda-
ta service ("datatosend”:[“url1”, “url2”,..., “urlx”])
Response (“data” field):
