AL1327 IO-Link master with EtherNet/IP interface
68
9.3 IoT Core Visualizer
The IoT Core Visualizer provides a graphical user interface to access the functions of the ifm IoT
Core.
9.3.1 Starting the IoT-Core Visualizer
To start the IoT-Core Visualizer:
Requirements:
ü The laptop / PC is connected directly or via a suitable network coupling unit (e.g. switch) to the IoT
port (X23) of the device.
ü The IoT interface is configured.
u Start the web browser.
u Go to the following URL: http://<ip-address>/web/subscribe (e.g. http://192.168.82.100/web/
subscribe )
w The web browser displays the start page of the IoT-Core Visualizer.
The navigation menu gives access to the following functions:
• [Notification]: Managing notifications (Ò/69)
• [Elements]: Searching for elements of the IoT Core (Ò/71)
• [Parameter]: Configuring the IO-Link master (Ò/72)
• [Processdata]: Accessing process data (Ò/73)
• [Update]: Update firmware (Ò/74)
