AL1327 IO-Link master with EtherNet/IP interface
66
Example: Publishing the temperature to an MQTT broker
Task: The temperature of the unit is to be published to an MQTT broker every 5 seconds (MQTT
broker: 192.168.82.100, port: 1883, topic: myTopic).
Solution:
u Setting the interval of the timer
Request:
{
"code":"request",
"cid":1,
"adr":"/timer[1]/interval/setdata",
"data":{
"newvalue":5000
}
}
u Publishing the temperature to an MQTT broker
Request:
{
"code":"request",
"cid":2,
"adr":"/timer[1]/counter/datachanged/subscribe",
"data":{
"callback":"mqtt://192.168.82.100:1883/myTopic",
"datatosend":["processdatamaster/temperature"]
}
}
Response:
{
"cid":2,
"code":200
}
9.2.25.9 WebSocket support
The ifm IoT-Core supports communication via WebSocket protocol. With WebSocket, the user can
establish a full-duplex communication channel via a TCP connection.
WebSocket can be used for the following services:
• subscribe
• unsubscribe
Maximum number of simultaneous WebSocket connections: 8
Secure WebSocket connections (wss://) are not supported.
To transmit notifications via a WebSocket connection:
u Establish a WebSocket connection (e.g. "ws://192.168.0.55:80/mywebsocket")
• Option 1: without parameter "callback”
u Send a subscribe/unsubscribe request without "callback” parameter.
w ifm IoT-Core sends notifications about existing WebSocket connections.
• Option 2: with parameter "callback”
