IO-Link master with EtherNet/IP interface AL1327
55
{
"cid":4711,
"code":200
}
9.2.18 IO-Link devices: Reading and writing device information
Substructure: iolinkmaster/port[x]/iolinkdevice (x: 1…8)
Available data points:
Name Description Value range Access
../status Status of the connected IO-Link de-
vice
• 0: State not connected - State not
connected
• 1: State preoperate - State
PREOPERATE
• 2: State operate - State OPERATE
• 3: State communication error - State
communication error
ro
1
../vendorid IO-Link ID of the manufacturer e.g. 310: ifm electronic ro
1
../deviceid IO-Link ID of the IO-Link device e.g. 712: ifm pressure sensor, PV7003 ro
1
../productname Product name of the IO-Link device e.g. PV7003 ro
1
../serial Serial number of the IO-Link device e.g. 000008500706 ro
1
../applicationspecifictag Application specific identification (ap-
plication tag)
e.g. sensor1_machine3 rw
2
1
Read only
2
Read and write
9.2.19 IO-Link devices: Reading IO-Link events
The device supports IO-Link events. IO-Link events are event and error messages. IO-Link events can
be generated in the IO-Link master and in the connected IO-Link devices. IO-Link events generated in
the IO-Link devices are forwarded to the IO-Link master and stored there.
An IO-Link event message has the following structure:
Byte 0…1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Event Code Source Validity Type Mode Instance
Legend
• Instance IO-Link Event Qualifier: Trigger 1 byte • 0x00: unknown
• 0x01: PL (Physical Layer)
• 0x02: DL (Data Layer)
• 0x03: AL (Application Layer)
• 0x04: APPL (Application)
• Mode IO-Link Event Qualifier: Event trigger 1 byte • 0x40: One-time event or warning
(single shot)
• 0xC0: Error disappeared
• 0x80: Error appeared
• Type IO-Link Event Qualifier: Event category 1 byte • 0x10: Notification
• 0x20: Warning
• 0x30: Error
• Validity Validity of the process data 1 byte • 0x00: Valid
• 0x40: Invalid
• Source IO-Link Event Qualifier: Event source 1 byte • 0x00: IO-Link device
• 0xFF: IO-Link master
