Je bekijkt pagina 51 van 125
IO-Link master with EtherNet/IP interface AL1327
51
0b000000010000000000000000000000000000000001001101 = 0x01000000004D
Request:
{
"code":"request",
"cid":10,
"adr":"iolinkmaster/port[2]/iolinkdevice/pdout/setdata",
"data":{"newvalue":"01000000004D"}
}
Response:
{
"cid":10,
"code":200
}
9.2.14.3 Example: Reading the digital input value (operating mode "DI")
Task: The digital input value of the IO-Link device at port 2 (pin 4) is to be read. The operating mode
of the IO-Link port is "Digital Intput (DI)".
Solution: Read the process value of the pdin data point. The process value is returned as a
hexadecimal value with a length of 1 byte (OFF = "00", ON = "01"').
Request:
{
"code":"request",
"cid":10,
"adr":"iolinkmaster/port[2]/iolinkdevice/pdin/getdata"
}
Response:
{
"cid":10,
"data":{
"value":"00"
},
"code":200
}
9.2.14.4 Example: Writing the digital output value (operating mode "DO")
Task: The digital output value of the IO-Link device at port 2 (pin 4) is to be set. The operating mode of
the IO-Link port is "Digital Output (DO)".
Solution: Write the process value of the pdout data point. The value has to be written as a
hexadecimal value with a length of 1 byte (OFF = "00", ON = "01"').
Request:
