AL1327 IO-Link master with EtherNet/IP interface
44
{
"cid":-1,
"code":200
}
9.2.7 IoT: Configuring the interface to the monitoring software
To enable transmission of the process data of the IO-Link master to the monitoring software (e.g. ifm
moneo suite), the interface must be configured accordingly.
Substructure: iotsetup
Available data points:
Name Description Value range Access
../smobip IP address of the monitoring software e.g. 255.255.255.255 (default) rw
1
../smobport Port number of the monitoring software • 0: 0
…
• 35100: 35100 (default)
…
• 65535: 65535
rw
1
../smobinterval Interval for data transmission to the moni-
toring software (value in milliseconds)
• 0: Off – no transmission (default)
• 500: 500ms
…
• 2147483647: 2147483647ms
rw
1
1
Read and write
9.2.8 Fieldbus: Configuring the EtherNet/IP interface
For communication with the EtherNet/IP network, the EtherNet/IP interface must be configured.
Substructure: fieldbussetup
Available data points:
Name Description Values Access
../network/dhcp Status of the DHCP client • 0: Static IP address:
• 1: DHCP (Dynamic Host
Configuration Protocol)
• 2: BOOTP (Bootstrap Protocol)
rw
1
../network/ipaddress IP address of the Ethernet interface: e.g. 192.200.0.100
• 192.168.1.250 (Default)
rw
1
2
../network/subnetmask Subnet mask of the network segment e.g. 255.255.192.0
• 255.255.255.0 (Default)
rw
1
2
../network/ipdefaultgateway IP address of the network gateway e.g. 192.200.63.1
• 0.0.0.0 (Default)
rw
1
2
../network/macaddress MAC address of the Ethernet interface e.g. 00:02:01:0E:10:7C ro
3
../hostname EtherNet/IP hostname e.g. alxx2x rw
1
../fieldbusfirmware Firmware of the fieldbus e.g. 5.3.0.10 (EtherNet/IP Adapter) ro
3
../connectionstatus Status of the fieldbus connection • 0: Not connected
• 1: Connected
ro
3
1
Read and write
2
The parameter can only be changed if no connection to the fieldbus controller is active
3
Read only
Applicable services:
