IO-Link master with EtherNet/IP interface AL1327
33
Field Parameter Description
code diag_code
Diagnostic code (Ò Diagnostic codes/33)
Example: POST request
Request:
{
"code":"request",
"cid":-1,
"adr":"devicetag/applicationtag/getdata"
}
Response:
{
"cid":-1,
"data":{"value":"Do not use"},
"code":200
}
Diagnostic codes
Code Text Description
200 OK Request successfully processed
230 OK but needs reboot Request successfully processed; Device needs to reboot
231 OK but block request not finished Request successfully processed; but block request not finished
233 IP settings (of IoT-Port) have been updated. Ap-
plication needs to reload device. Wait at least 1
second before reloading the device.
The IP settings have been successfully changed, IO-Link master
will be reloaded; wait for at least 1 second
400 Bad request Invalid request
401 Unauthorized Unauthorized request
403 Forbidden Forbidden request
500 Internal server error Internal fault. detailed information in the "error" field
503 Service unavailable Service not available (e.g. IO-Link port in wrong operating mode;
no IO-Link device on IO-Link port)
507 Insufficient Storage The internal memory for notifications is full (max. 16 kB)
530 The requested data is invalid Invalid process data
531 IO-Link Error Error in IO-Link master / IO-Link device; detailed information in
the "error" field
532 PLC connected Error Error when writing data because IO-Link master is still connect-
ed to fieldbus PLC
9.2.2 Getting started
To read the device description:
u Send the following POST request to the ifm IoT Core:
{"code":"request","cid":-1,"adr":"gettree"}
w The ifm IoT Core returns the device description as a structured JSON object.
u Identify all substructures and the data points contained therein in the tree structure of the JSON
object.
u Identify the applicable services for the access to substructures and the data points contained
therein.
