AL1327 IO-Link master with EtherNet/IP interface
20
3
Read only
To configure the IoT interface:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
ü The detailed view of the device is active.
u Select [IoT] menu.
w The menu page shows the current settings.
u Set IP parameters.
u Write the changed values to the device.
w IP settings of the IoT interface are configured.
9.1.4 IoT: Configuring access rights
The device can be integrated in parallel into a fieldbus environment and into an IT network structure
for IIoT applications (“Y-path”).
Available parameters:
Parameter Description Value range Access
Access rights Access rights to the device • Fieldbus + IoT:
– Fieldbus and ifm IoT Core have read and write
access rights to parameters and process data
– Fieldbus and ifm IoT Core have read and write
access rights to parameters and process data
• Fieldbus + IoT (read only):
– Fieldbus has read and write access rights to
parameters and process data
– Fieldbus has read access rights to events /
alarms
– ifm IoT Core has read access rights to
parameters, process data and events / alarms
• IoT only
– ifm IoT Core has read and write access rights to
parameters and process data
– ifm IoT Core has read access rights to events /
alarms
– Fieldbus has no access rights
rw
1
1
Read and write
When setting the parameters of the access rights in the parameter setting software, observe the
following notes:
• If the access rights in the fieldbus projection software and the parameter setting software are set to
the [Fieldbus + IoT] value, the parameter values set on the fieldbus side always apply.
• For exclusive access to the device via the parameter setting software, set the access rights to the
[IoT only] value and set the access rights to [Keep settings] in the fieldbus projection software.
• If the access rights in the parameter setting software have been set to the [Fieldbus + IoT (read
only)] value, the access rights in the parameter setting software can no longer be changed. To
regain write access with the parameter setting software, set the access rights in the fieldbus
projection software to the [Fieldbus + IoT] value.
To configure the access rights:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
