AL1327 IO-Link master with EtherNet/IP interface
124
11.2.4.11 Ethernet Link Object (Class Code: 0xF6)
Class attributes
Attr. ID Access Name Data type Description Value
1 Get Revision UINT Revision of the object 4
2 Get Max. Instance UINT Max. number of instances of the object 2
3 Get Number of instances UINT Number of instances 2
6 Get Max. ID Number Class
Attributes
UINT Max. ID number of a class attribute 7
7 Get Max. ID Number In-
stance Attribute
UINT Max. ID number of the instance attribute 300
Instance attributes
Attr. ID Access Name Data type Description Default
1 Get Interface Speed UDINT Current transmission rate
• 10: 10 Mbit/s
• 100: 100 Mbit/s
100
2 Get Interface Status Flag DWORD Interface status flags
• Bit 0: link status
• Bit 1: half/full duplex
• Bit 2…4: negotiation status
• Bit 5: manual change
requires reset
• Bit 6: local hardware error
• Bit 7…31: reserved
0x20
3 Get Physical Address ARRAY(6) of
USINT
MAC address
4 Get Interface Counters STRUCT(11)
of UDINT
Interface-specific counter
5 Get Media Counters STRUCT(12)
of UDINT
Medium-specific counter
6 Get / Set Interface Control STRUCT of Interface control
• Interface Settings DWORD Settings
Bit 0:
• 0: auto-negotiation on
• 1: auto-negotiation off
Bit 1:
• 0: half duplex
• 1: full duplex
0
• Interface Speed UINT Transmission rate
• 10: 10 Mbit/s
• 100: 100 Mbit/s
7 Get Interface type USINT • 0: unknown
• 1: internal interface
• 2: twisted pair
• 3: optical fibre
2
8 Get Interface State USINT Current status of the interface
• 0: unknown
• 1: active; ready for
transmission and reception
• 2: not active
• 3: test mode
0
