AL1327 IO-Link master with EtherNet/IP interface
122
11.2.4.10 TCP/IP Object (Class Code: 0xF5)
Class attributes
Attr. ID Access Name Data type Description Value
1 Get Revision UINT Revision of the object 4
2 Get Max. Instance UINT Max. number of instances of the object 1
3 Get Number of instances UINT Number of instances of the object 1
6 Get Max. ID Number Class Attrib-
utes
UINT Max. ID number of a class attribute 7
7 Get Max. ID Number Instance At-
tribute
UINT Max. ID number of the instance attribute 13
Instance attributes
Attr. ID Access Name Data type Description Default
1 Get Status UINT Status of the TCP/IP interface
• 0: interface not configured
• 1: interface configured with DHCP,
BOOTP or non-volatile memory
2 Get Configuration Capability DWORD Configuration options for interface
• Bit 0: BOOTP Client
• Bit 2: DHCP Client
• Bit 4: configuration adjustable
• Bit 7: ACD-capable
0x95
(BOOTP,
DHCP,
TCP/IP
configur-
able, ACD
capable)
3 Get / Set Configuration Control DWORD Configuration control
Bit 0..3: startup configuration
• 0: statically assigned IP address
• 1: configuration via BOOTP
• 2: configuration via DHCP
0
4 Get Physical Link Object Path STRUCT of Logical path to the physical communica-
tion interface (Ethernet link object)
• Path Size UINT Length (number of words, little endian for-
mat)
0x0200
• Path Padded
EPATH
Class ID: 0xF6 (Ethernet Link Object)
• Instance ID: 0x1
0x20F62
401
5 Get / Set Interface configuration STRUCT of TCP/IP interface configuration
• IP Address UDINT IP address 192.168.1.
250
• Network Mask UDINT Network mask 255.255.2
55.0
• Gateway Address UDINT Gateway address 0.0.0.0
• Name Server UDINT Primary name server 0.0.0.0
• Name Server 2 UDINT Secondary name server 0.0.0.0
• Domain Name STRING Default domain name 0
6 Get / Set Host Name STRING Host Name
• 0: not configured
0
8 Get TTL Value UINT TTL value 1
9 Get / Set Mcast Config UINT Mcast configuration 0
10 Get / Set SelectAcd BOOL ACD activation / deactivation
• 0: deactivated
• 1: activated
1
11 Get / Set Last conflict detected STRUCT of Last conflict detected 0
