IO-Link master with EtherNet/IP interface AL1327
117
CIP Format Data type MSG Config Description
CIP User Specific Service Data USINT <> 0x00 IO-Link Additional Code: Additional Code
(Ò/102)
CIP Error Code:
Code Description
0x02 Resource not available: The IO-Link port is busy processing another acyclic service.
0x05 Invalid class ID or instance ID
0x08 Wrong service ID: only service 0x4B, 0x4C or 0x4D is permitted
0x09 Wrong attribute ID: wrong port number
0x20 Invalid parameter value (e.g. invalid length)
0x1E Embedded service error: Error occurred during an IO-Link service. Byte 0 and byte 1 of the CIP User Specific
Service Data contain the IO-Link error code and an additional code returned by the IO-Link master.
