AL1327 IO-Link master with EtherNet/IP interface
112
11.2.4.6 Connection Manager Object (Class Code: 0x06)
Class attributes
Attr. ID Access Name Data type Description Value
1 Get Revision UINT Revision of the object 1
2 Get Max. Instance UINT Max. number of instances of the object 1
3 Get Number of instances UINT Number of instances 3
6 Get Max. ID Number Class
Attributes
UINT Max. ID number of a class attribute 7
7 Get Max. ID Number In-
stance Attributes
UINT Max. ID number of the instance attribute 0
Instance attributes
The object class has no instance attributes.
Services
Code Service Class Instance Description
0x0E Get Attribute Single Yes Yes Read single attribute
0x10 Set Attribute Single No Yes Write single attribute
0x4E Forward Close Yes No Close connection
0x54 Forward Open Yes No Open new connection
