IO-Link master with EtherNet/IP interface AL1327
111
11.2.4.5 Assembly Object (Class Code: 0x04)
Class attributes
Attr. ID Access Name Data type Description Value
1 Get Revision UINT Revision of the object 2
2 Get Max. Instance UINT Max. number of instances of the object 0x00C7
3 Get Number of instances UINT Number of instances 3
6 Get Max. ID Number Class At-
tributes
UINT Max. ID number of the class attribute 7
7 Get Max. ID Number Instance
Attributes
UINT Max. ID number of the instance attribute 4
Instance attributes
Attr. ID Access Name Data type Description Default
1 Get Number of Members UINT Number of members in list --
2 Get Member UINT List of members --
3 Get / Set Data UINT Current process data image --
4 Get Size UINT Process data length (number of
bytes)
--
300 -- Member data list UINT Data of the Assembly members --
301 Get Parameter UINT Assembly parameters --
302 Get Status UINT Assembly status --
The following object instances are available:
• Configuration Assembly (Instance 199) (Ò/87)
• Input Assembly (Instance 100) (Ò/90)
• Input Assembly (Instance 101) (Ò/91)
• Input Assembly (Instance 102) (Ò/92)
• Output Assembly (Instance 150) (Ò/96)
• Output Assembly (Instance 151) (Ò/96)
Services
Code Service Class Instance Description
0x0E Get Attribute Single Yes Yes Read single attribute
0x10 Set Attribute Single No Yes Write single attribute
