AL1327 IO-Link master with EtherNet/IP interface
108
11.2.4.3 Identity Object (Class Code: 0x01)
Class attributes
Attr. ID Access Name Data type Description Value
1 Get Revision UINT Revision of the object 2.003
2 Get Max. Instance UINT Max. number of instances of the object 1
6 Get Max. ID Number Class
Attributes
UINT Max. ID number of a class attribute 7
7 Get Max. ID Number In-
stance Attributes
UINT Max. ID number of the instance attribute 9
Instance attributes
Attr. ID Access Name Data type Description Default
1 Get Vendor ID UINT Manufacturer ID 322
2 Get Device Type UINT Device type 12
3 Get Product Code UINT Product code of the device 1008
4 Get Revision STRUCT Revision of the device 2.003
• Major Revision USINT Major revision (1...127) 2
• Minor Revision USINT Minor revision (3 digits) 003
5 Get Status WORD Overall status of the device
6 Get Serial Number UDINT Serial number of the device --
7 Get Product Name SHORT
STRING
Product name of the device IO-Link Mas-
ter DL EIP 8P
IP69K
8 Get State USINT State of the device (State machine)
• 0: Nonexistent
• 1: Device Self Testing
• 2: Standby
• 3: Operational
• 4: Major Recoverable Fault
• 6-254: Reserved
• 255: Default for “Get_Attributes_All”
service
9 Get Configuration Consistency
Value
UINT The content shows the configuration of
the device
0
Services
Code Service Class Instance Description
0x01 Get Attribute All Yes Yes Read all attributes
0x05 Reset Yes Yes Reset
0x0E Get Attribute Single Yes Yes Read single attribute
0x10 Set Attribute Single Yes Yes Write single attribute
If an Identity Object receives a reset request, it carries out the following actions:
• It checks if it supports the requested reset type.
• It responds to the request.
• It tries to execute the requested reset type.
Supported reset types:
• 0: reboot the device (mandatory for all EtherNet/IP devices).
