IO-Link master with EtherNet/IP interface AL1327
107
11.2.4 Object directory
11.2.4.1 CIP object classes
Supported object classes:
Class Code Name Description
0x01 Identity Object
Identity Object (Class Code: 0x01) (Ò/108)
0x02 Message Router Object
Message Router Object (Class Code: 0x02) (Ò/110)
0x04 Assembly Object
Assembly Object (Class Code: 0x04) (Ò/111)
0x06 Connection Manager Object
Connection Manager Object (Class Code: 0x06) (Ò/112)
0x47 Device Level Ring Object
Device Level Ring Object (Class Code: 0x47) (Ò/113)
0x48 Quality Of Service Object
Quality Of Service Object (Class Code: 0x48) (Ò/114)
0x80 IO-Link Request Object
IO-Link Request Object (Class Code: 0x80) (Ò/115)
0xF5 TCP/IP Object
TCP/IP Object (Class Code: 0xF5) (Ò/122)
0xF6 Ethernet Link Object
Ethernet Link Object (Class Code: 0xF6) (Ò/124)
11.2.4.2 CIP class and instance services
Supported class and instance services:
Service code Name Description
0x01 Get Attribute All Read all attributes
0x02 Set Attribute All Write all attributes
0x05 Reset Reset
0x09 Delete Delete
0x0E Get Attribute Single Read single attribute
0x10 Set Attribute Single Write single attribute
0x4B Read ISDU Read ISDU
0x4C Write ISDU Write ISDU
0x4D Write Failsafe Pattern Write fail-safe values
0x4E Forward Close Close connection
0x54 Forward Open Open new connection
