AL1327 IO-Link master with EtherNet/IP interface
100
Response channel
Byte
(offset)
Bit
7 6 5 4 3 2 1 0
4 Port No. (LSB)
5 Port No. (MSB)
6 Index (LSB)
7 Index (MSB)
8 Subindex (LSB)
9 Subindex (MSB)
10 Handshake Command ID
11 Result
12 Data Length
13 Data (Byte 0) | Error Code
14 Data (Byte 1) | Additional Code
…
44 Data (Byte 31)
45 reserved
Legend:
• Port No. IO-Link Port
Port No. 0x1234
• Port No. (MSB): 0x12
• Port No. (LSB): 0x34
1WORD • 0x0001: Port 1
• 0x0002: Port 2
• 0x0003: Port 3
• 0x0004: Port 4
• 0x0005: Port 5
• 0x0006: Port 6
• 0x0007: Port 7
• 0x0008: Port 8
• Index Index of the ISDU object
Index: 0x1234
• Index (MSB): 0x12
• Index (LSB): 0x34
1WORD 0x0000…0xFFFF
• Subindex Subindex of the ISDU object
Subindex 0x1234
• Subindex (MSB): 0x12
• Subindex (LSB): 0x34
1WORD 0x0000…0xFFFF
• Handshake Validity of the IO-Link response data 1BIT • 0x0: data invalid
• 0x1: data valid
• Command ID Command number 7BIT • 0x01: Get
• 0x02: Write
• Result Status of the command processing 1BYTE • 0x00: OK
• 0x0F: OK, data user read > 32 bytes
• 0xFF: Error
• Data Length Number of bytes that contain relevant user
data
1BYTE • 0x00: 0 bytes
…
• 0x20: 32 bytes
• Data (Byte 0) |
Error Code
User data (byte 0) or error codes 1BYTE • User data: 0x00…0xFF
• Error Code: Error Code (Ò/102)
• Data (Byte 1) |
Additional Code
User data (byte 1) or additional error codes 1BYTE • User data: 0x00…0xFF
• Additional Code: Additional Code
(Ò/102)
