AL1325 IO-Link master with EtherNet/IP interface
64
The following options are additionally available:
via WebSockets (ws://): Example: Using WebSockets
via MQTT (mqtt://): Example: Configuring the MQTT command channel (Ò Example: Configure
and activate MQTT command channel/61)
Solution:
u Subscribe to the required data using the subscribe service.
• Request:
{
"code":"request",
"cid":4711,
"adr":"/timer[1]/counter/datachanged/subscribe",
"data":{
"callback":"http://192.168.0.4:80/temp",
"datatosend":[
"/iolinkmaster/port[2]/iolinkdevice/pdin",
"/processdatamaster/temperature"]
}
}
u Set the timer to 500 ms.
• Request:
{
"code":"request",
"cid":4712,
"adr":"/timer[1]/interval/setdata",
"data":{
"newvalue":500
}
}
• Response:
{
"cid":4712,
"code":200
}
• Notification (Format: JSON)
{
"code":"event",
"cid":4711,
"adr":"",
"data":{
"eventno":"6317",
"srcurl":"/timer[1]/counter/datachanged",
"payload":{
"/timer[1]/counter":{"code":200,"data":1},
"/processdatamaster/temperature":{"code":200,"data":39},
"/iolinkmaster/port[2]/iolinkdevice/pdin":{"code":200,"data":"03B0"}
}
}
}
