IO-Link master with EtherNet/IP interface AL1325
63
u Set standard response topic.
Request:
{
"code":"request",
"cid":5,
"adr":"/connections/mqttConnection/mqttCmdChannel/mqttCmdChannelSetup/
defaultReplyTopic/setdata",
"data":{
"newvalue":"stdTopic"
}
}
Example: Publishing the temperature to an MQTT broker
Task: The temperature of the unit is to be published to an MQTT broker every 5 seconds (MQTT
broker: 192.168.82.100, port: 1883, topic: myTopic).
Solution:
u Setting the interval of the timer
Request:
{
"code":"request",
"cid":1,
"adr":"/timer[1]/interval/setdata",
"data":{
"newvalue":5000
}
}
u Publishing the temperature to an MQTT broker
Request:
{
"code":"request",
"cid":2,
"adr":"/timer[1]/counter/datachanged/subscribe",
"data":{
"callback":"mqtt://192.168.82.100:1883/myTopic",
"datatosend":["processdatamaster/temperature"]
}
}
Response:
{
"cid":2,
"code":200
}
9.2.25.4 Example: Subscribing to notifications
Task: Every 0.5 seconds, the current values of the following parameters are to be sent regularly to a
network server with the IP address 192.168.0.4/temp.
• cyclic IO-Link input data of the IO-Link device at IO-Link Port 2
• Operating temperature of the IO-Link master.
