IO-Link master with EtherNet/IP interface AL1325
53
Name Description Value range Access
../portevent Port event
Structure: 0xYYZZ00
• 0xYY: Device Status - Status of
the IO-Link devices
• 0xZZ: Connection Status - Status
of the connection
Device status:
• 0x00: No IO-Link device connected
• 0x40: Wrong IO-Link device connected
• 0x80: IO-Link device connected and in
PREOPERATE state
• 0xFF: IO-Link device connected and in
OPERATE state
Connection Status:
• 0x00: Port deactivated
• 0x01: Port activated, but no device
connected
• 0x02: Port activated and in “IO-Link”
operating mode
• 0x03: Port activated and in “DI” operating
mode
• 0x04: Port activated and in “DO” operating
mode
• 0x1B: Repetitions detected
• 0x1E: Short circuit detected at pin 4
• 0x42: Wrong revision of the IO-Link device
• 0x43: Wrong vendor ID (V1.1 Revision)
• 0x44: Wrong device ID (V1.1 Revision)
• 0x45: Wrong vendor ID (V1.0 Revision)
• 0x46: Wrong device ID (V1.0 Revision)
• 0x48: Wrong cycle time
ro
1
1
Read only
9.2.16 Timer: Configuring the timers
The unit has 2 timers. The timers can be used for time-triggered transmission of notifications.
Die Zeitgeber sind werkseitig aktiv.
Substructure: timer[1] | timer[2]
Available data points:
Name Description Value range Access
../counter Counter reading • 0…4294967295 rw
1
../interval Counting interval (value in ms) • 1000: 1000 ms
…
• 86400000: 86400000 ms
rw
1
../interval/unit Unit of the counting interval • ms: milliseconds ro
2
1
Read and write
2
Read only
9.2.16.1 Set the counting interval
Task: The counting interval of timer 2 is to be set to 2.5 s.
Solution: Mit dem Dienst setdata den neuen Wert 2500 auf den Datenpunkt /timer[2]/interval
schreiben (2500ms = 2,5s).
Request:
