AL1325 IO-Link master with EtherNet/IP interface
32
POST method
Access: reading, writing
Syntax of the request:
{
"code":"code_id",
"cid":id,
"adr":"data_point/service",
"data":{req_data},
"auth":{"user":"usr_id","passwd":"password"}
}
Field Parameter Description
code code_id Service class
• request: request
• transaction: transaction
• event: event
cid id Correlation ID for the assignment in pairs of request and response; identifier freely assignable
by the user
adr data_point Data point of the element tree to be accessed
service Service to access the data point
data
1
req_data Data sent to the ifm IoT Core (e.g. new values); syntax depending on the service
auth
2
usr_id User name (BASE64-encoded); default: administrator
password Password (BASE64-encoded)
1
optional; only required for services that send data to the ifm IoT Core (e.g. setdata )
2
optional; only required if security mode is activated
Syntax of the response:
{
"cid":id,
"data":{resp_data},
"code":diag_code
}
Field Parameter Description
cid id
Correlation ID for the assignment of request and response (Ò Request)
data
1
resp_data Values returned by the ifm IoT Core; syntax depending on the service
code diag_code
Diagnostic code (Ò Diagnostic codes/33)
1
optional; only available for services that receive data from the ifm IoT Core (e.g. getdata )
Device-specific error codes are output in the event of faulty acyclic access to connected IO-Link
devices.
Syntax of the response in the event of incorrect access:
{
"cid":id,
"error":err_code,
"code":diag_code
}
Field Parameter Description
cid id
Correlation ID for the assignment of request and response (Ò Request)
error err_code
device-specific error code (Ò IO Device Description (IODD) of the IO-Link device)
