IO-Link master with EtherNet/IP interface AL1325
21
u Select the [IoT] menu.
w The menu page shows the current settings.
u Set the access rights.
u Write the changed values to the device.
u Restart the device.
w The changed access rights are active.
9.1.5 IoT: Configuring the interface to the monitoring software
Für die optionale Übertragung der Prozessdaten an eine Monitoring-Software muss die Schnittstelle
entsprechend konfiguriert werden.
Available parameters:
Parameter Description Value range Access
IP address Moneo, LR
Agent or SMARTOBSERV-
ER
IP address of moneo, LR AGENT or
LR SMARTOBSERVER
• 0.0.0.0
…
• 255,255,255,255 (default)
rw
1
Port Moneo, LR Agent or
SMARTOBSERVER
Number of the moneo port, LR AGENT
or LR SMARTOBSERVER to which the
process data is sent
• 0
…
• 35100 (default)
…
• 65535
rw
1
Interval Moneo, LR Agent or
SMARTOBSERVER
Cycle time for the transfer of the pro-
cess data to moneo, LRAGENT or
LRSMARTOBSERVER (value in ms)
• Off: No transmission (default)
• 500: 500 ms
…
• 2147483647: 2147483647 ms
rw
1
Application tag Source identifier of the IO-Link master
in the structure of the LR AGENT or LR
SMARTOBSERVER (String32)
e.g., “factory 2 plant 1” rw
1
1
Read and write
After changing the parameters [IP address Moneo, LR Agent or SMARTOBSERVER] or
[Application Tag], it may take up to 20 seconds until the device will establish a TCP connection
again.
To prevent the delay:
u Restart the device.
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
u Select [IoT] menu.
w The menu page shows the current settings.
u Configuring the interface
u Save the changes on the device.
w Interface to the monitoring software has been set.
9.1.6 IoT: Configuring security mode
The unit provides a security mode. The security mode makes it possible to protect access to IO-Link
masters and connected IO-Link devices from the IT network. When security mode is activated, the
following restrictions apply:
