Je bekijkt pagina 19 van 121
IO-Link master with EtherNet/IP interface AL1325
19
9 Settings
9.1 Parameter setting software
9.1.1 Supported parameter setting software
Für die Parametrierung des IO-Link Masters und der angeschlossenen IO-Link Devices wird eine
Parametriersoftware benötigt.
Supported parameter setting software
• ifm moneo OS (Art.-Nr. QMS001) + Modullizenz ifm moneo|configure (Art.-Nr. QMP020)
• ifm moneo|configure SA (Art.-Nr. QMP010)
u Für die korrekte Installation: Installationsanleitung ifm moneo beachten.
u Install the desired parameter setting software.
u Activate the licences required for operation.
w The installed parameter setting software can be used for parameter setting of the device.
9.1.2 Getting started
Requirements:
ü The parameter setting software is correctly installed on the laptop/ PC.
ü The laptop / PC is connected to the IoT port of the unit.
u Start the parameter setting software.
u Scan the network for devices.
w The parameter setting software recognises the device.
u Optional: Adapt the IP settings of the device.
w The parameter setting software can access the IO-Link master and the connected IO-Link devices.
9.1.3 IoT: Configuring IP settings
For communication with the IT network, the IP parameters of the IoT interface must be configured.
Available parameters:
Parameter Description Value range Access
DHCP Enable / disable the DHCP client • Static IP: DHCP client disabled IP
parameters are set by the user
• DHCP: DHCP client enabled; IP
parameters are set by the network's
DHCP server.
rw
1
IP address IP address of the IoT interface e.g. 192.168.1.100
169.254.x.x(default)
rw
1
2
Subnet mask Subnet mask of the Ethernet network e.g. 255.255.255.0
255.255.0.0 (Default)
rw
1
2
Default gateway IP address IP address of the network gateway e.g. 192.169.1.1
0.0.0.0 (Default)
rw
1
2
MAC address MAC address of the IoT interface e.g. 00:02:01:0E:66:C1 ro
3
1
Read and write
2
can only be changed if DHCP is disabled
