Function and features
• The controller
e
integrates one or two AS-i masters
(AC1309/AC1310, both in accordance with the AS-i version 2.1), a
mini controller and an Ethernet interface.
• It controls the exchange of data to the sensor / actuator level
• processes the peripheral data in the integrated processor (signal pre-
processing)
• works as stand-alone controller with exchange of data to the PC
(visualisation)
• communicates with the higher control level (in the gateway mode)
Programming interface RS232C
• Baud rate 4800 to 115,200 baud
• Max. distance between controller
e
and host: 20m
• Potential separation from the controller
e
power supply
• Programming cable E70320 for connection to host required
Ethernet interface
• 10Mbps and 100Mbps
• TCP/IP - Transport Control Protocol/ Internet Protocol
• UDP - User Datagram Protocol
• IT functionality: file system, FTP server, Telnet server, HTTP server, E-
mail client
• RJ45, Twisted-Pair
Installation
Fix the controller
e
onto a 35mm rail. The protection rating of the unit
is IP20, therefore it should be mounted in a protected location (e.g.
control cabinet).
Ensure a condensation-free environment. Avoid excessive dust,
vibration and shock. The air circulation through the vents must
not be impeded.
Avoid installation in direct vicinity of frequency inverters.
PAGE 9
