Diagnosis / adjustment
The AS-i controller is served via the higher-level host (PC). Some func-
tions are accessible locally:
Assignment of the status nibbles:
PAGE 17
Mode Action Operating steps
1 display list of failed slaves see error messages
2 display detected slaves 0/1, 0/2, 2 - 4
3 display projected slaves 0/1, 0/2, 2 - 4
4 display activated slaves 0/1, 0/2, 2 - 4
5 allocate address 0 to a slave 0/1, 0/2, 5
6 allocate an address to slave 0 0/1, 0/2, 6
7 auto addressing on / off 0/1, 7
8 project slaves 0/1, 0/2, 8
9 program processing run/stop 0/1, 9
A address controller 0/1, A
b set transfer rate of the serial interface 0/1, B
locking/unlocking modes > 4 locking/unlocking
Bit no. = 1
Meaning
7 running
signal preprocessing
6 not o.k.
AS-i power / configuration
5 yes
running up finished
4
= 0
stopped
o.k.
no
reserved
