• Are the air outlets of the indoor and outdoor units free of obstacles? Yes No
• Has each of the pipe connections been checked for gas leaks? Yes No
• Is the voltage at the exclusive power outlet within the range
of rated voltage +/- 10% of standard 220 volts? Yes No
• Are the fuse and wire gauge used of the following specifications? Yes No
12K 18K 24K
Fuse (MCB Rating) 12A 16A 16A/25A
2 2 2
Wire Size 1.5mm 1.5mm 1.5mm
• Run the machine for 30 minutes and check for the following:
a) Vibration/abnormal noise heard? Yes No
b) Electric power supply input volts and earthing for the unit
1) Voltmeter reading more than 100 mV and less than 3 V
between N&E? Yes No
2) Supply between L&E - Rated Voltage +/-10%? Yes No
3) Supply between L&N - Rated Voltage +/- 10%? Yes No
N = Neutral, L = Line, E = Earth
• Temperature readings taken
0
Indoor Unit Return Air Temp ____________ C (T1) Yes No
0
Indoor Unit Supply Air Temp ____________ C (T2) Yes No
0
Delta T = _______ (T1- T2) between 8-14 C? Yes No
• Checked drainage of condensed water from evaporator side Yes No
to drain outlet by pouring water at the base of evaporator coil? Yes No
31
34
