Key information for installer
Inverter Type Capacity (Btu/h)
Liquid pipe diameter
Gas pipe diameter
Length of pipe with
standard charge
Maximum distance between
indoor and outdoor unit
Additional refrigerant charge
Maximum difference in level
between indoor and outdoor unit
Type of refrigerant
(Ø 6.35)
1
4
’’
3
8
’’
(Ø 9.52)
3 m
15 m
20 g/m
5 m
R32
1
2
’’
(Ø 12.7)
3 m
15 m
20 g/m
5 m
R32
12k 15/18k 22/24k
(Ø 6.35)
1
2
’’
(Ø 12.7)
3 m
15 m
20 g/m
5 m
R32
1
4
’’
(Ø 6.35)
1
2
’’
(Ø 12.7)
3 m
15 m
20 g/m
5 m
R32
1
4
’’
Wiring diagram
The wiring diagram may vary according to model. Please check the wiring diagram under
the top panel on the right hand side of the indoor unit as well as the back of the outdoor unit
handle cover.
25
Outdoor Unit
Wiring Diagram
Top Panel
Wiring Diagram
Outdoor
Handle
Cover
*Wiring diagram may vary according to model.
Indoor Unit : Under the front panel & over the control box cover as shown above in 1.
Outdoor Unit : Under the top panel & over the control box cover OR at the back side of the
outdoor unit handle cover* as shown above in 2.
