Type of fuse used on indoor unit controller for 12k, 15k, 18k, 22k, 24k, 24k and 30k is
rated 4A, 250 V.
Type of fuse used on inverter outdoor unit controller for 12k is rated 15 A, 250 V. Type of fuse
used on inverter outdoor unit controller for 18k, 22k and 24k is rated 20 A, 250 V.
Cable wire specifications
P
Model Capacity (Btu/H)
12K 18K 24K
Sectional Area
2 2 2
ower supply cable N 1.5 mm 1.5 mm 1.5 mm
2 2 2
L 1.5 mm 1.5 mm 1.5 mm
2 2 2
1.5 mm 1.5 mm 1.5 mm
2 2 2
Connection supply N 1.5 mm 1.5 mm 1.5 mm
cable
2 2 2
L 1.5 mm 1.5 mm 1.5 mm
2 2 2
1 1.5 mm 1.5 mm 1.5 mm
2 2 2
1.5 mm 1.5 mm 1.5 mm
NOTE:
Wire diameters are as per American wire gauge (AWG) standard.
26
29
Cable wire specifications
Model Capacity (Btu/H)
12K 18K 24K
Sectional Area
2 2 2
Power supply cable N 1.0 mm 1.5 mm 1.5 mm
2 2 2
L 1.0 mm 1.5 mm 1.5 mm
2 2 2
1.0 mm 1.5 mm 1.5 mm
2 2 2
Connection supply N 1.0 mm 1.5 mm 1.5 mm
cable
2 2 2
L 1.0 mm 1.5 mm 1.5 mm
2 2 2
1 1.0 mm 1.5 mm 1.5 mm
2 2 2
1.0 mm 1.5 mm 1.5 mm
NOTE:
Wire diameters are as per American wire gauge (AWG) standard.
