14
For the network keyboard to properly control a device, the device must be registered on the network keyboard. Basic
and Advanced modes are supported for registration and control of the device, and the device can be controlled only
in the mode for which it was registered. When controlling devices via RS485 connection only, you can register them in
Basic or Advanced mode. When controlling devices by using a network and RS485 connection, you can register them
only in Advanced mode. Both the LCD menus and the IDIS Discovery program can be used for registration in Basic
mode, and the IDIS Discovery program can be used for registration only in Advanced mode.
Part 2 - Installation
PTZ Camera Registration
You can register PTZ cameras for control via RS485 connection. PTZ cameras with dierent ports can be controlled
only in Advanced mode.
Basic Mode
PTZ cameras can be directly registered using the network keyboard with the LCD menus or remotely using the IDIS
Discovery program. For more information about remote registration, see Part 5 - Remote Setup > Devices. The
following explains how to perform registration with the LCD menus.
1
Connect a PTZ camera to the RS485 PTZ port on the network keyboard after referring to the operation manual of
the PTZ camera.
2
Enter into the LCD menu by pressing
1 0
SHIFT ESC DEV PANE MON
F1
MON DEV ESC F3 F4PANE
SHIFT
+
1 0
SHIFT ESC DEV PANE MON
F1
MON DEV ESC F3 F4PANE SHIFT
on the network keyboard. For more information about LCD
menu entry and conguration, see Part 4 - LCD Menu Conguration.
3
Select Device > General.
• Setup Type: Select Basic (Basic mode).
• Port: Select PTZ and set up port information for RS485 communication referring to the settings in the PTZ
camera.
→ → →
→ → →
