10
OPERATING INSTRUCTION
MOBILE FRIDGE ID5501
EN
INSTRUKCJA OBSŁUGI
FAN HEATER HL12
• GENERAL DESCRIPTION
1. Handle
2. Control panel
3. Power supply panel
4. Ventilation openings
5. Cover
6. Body
7. Power cord 12V (automotive)
8. Power cord 220-240V
A. ECO switch
B. On/Off switch
C. Display
D. Control buttons
E. AC power socket
F. DC power socket
G. USB socket
• INTENDED USE
The ID5501 travel fridge combines dual, integrated cooling and heating functions through
the use of a semiconductor (Peltier cell), without the use of a compressor or cryogenics. Among the product's
advantages are its eco-friendliness, small size, negligible weight, long service life and low energy
consumption.
The ID5501 travel fridge is not a complete replacement for a stationary domestic fridge.
It operates with a different cooling technique and under varying external conditions, and therefore
the parameters, operation and performance of the two products are not comparable. The unit cools
to a maximum of 15°C below ambient temperature. It heats to a temperature of approximately 60°C.
For optimum cooling effect, it is recommended to insert unfrozen products. Cooling will take between
2 and 3 hours.
The appliance is not designed to reheat cold products, but to keep hot meals at a high temperature.
If the appliance is operated correctly and according to the instructions, the temperature of the products
can be maintained for many hours.
The handle (1) protects the lid from opening. Opening the lid (5) is only possible when the handle
is folded down.
• OPERATION
After unpacking the device, make sure that it has not been damaged in transit. If in any doubt, refrain from
using it until you contact a service center.
The unit can be powered by 12V or 220-240V, using the supplied power cables (7) and (8), without additional
accessories.
NOTE
Do not connect two power cables at the same time - this may damage the appliance and invalidate
the warranty.
Do not cover the ventilation openings when the unit is in operation
• DANE TECHNICZNE
− Power for 12V power supply:
cooling: 45W
heating: 43W
− Power for 220-240V:
cooling: 60W
heating: 55W
ECO: 8,6W
− Supply voltage:
12V lub 220-240V~ 50Hz
USB: 5V, 2A
− Storage capacity: 29l
NOTE
The value set with the "D" buttons does not represent the set temperature. It only indicates
the intensity level of the unit. The value of the temperature reached by the appliance depends, among
other things, on the value of the outside temperature and the quantity and temperature
of the products placed inside.
220-240V AC POWER SUPPLY
− Place the unit on a flat and stable Surface.
− Connect one end of the power cord (8) to the "E" socket and the other end to the mains socket.
− Switch the unit on using the "B" button. The display "C" will show the temperature value inside
the appliance.
− Use the "D" buttons to set the operating mode (positive value - heating, negative value - cooling)
and the intensity level.
− Optionally, the ECO function can be activated using button "A".
The ECO function only works with a 220-240V power supply. Current consumption is reduced
in this case. The ECO function can be used, for example, when storing small quantities of food.
12V DC POWER SUPPLY (CAR SUPPLY)
− Place the unit on a flat and stable surface.
− Plug one end of the power cord (7) into the "F" socket and the other end into the car's cigarette lighter
socket.
− Switch the unit on using the "B" button. The display "C" will show the temperature value inside
the appliance.
− Use the "D" buttons to set the operating mode (positive value - heating, negative value - cooling)
and the intensity level.
USB socket 5V, 2 A
− is used to charge devices.
• Recommendations
− store foodstuffs in their own packaging to prevent the direct effects of frosting or condensation
and the permeation of odours,
− in the case of vehicle power supply, do not operate the refrigerator from the power socket when
the vehicle is stationary (engine switched off).
− in the case of car power supply, do not operate the fridge from the cigarette lighter socket
for more than 3 hours when the car is not in use (the car engine is switched off) - prolonged
operation leads to excessive battery discharge,
− a change of temperature in the insulated container (frequent opening or switching off) leads to natural
phenomena in the form of frost or condensation visible on the walls of the container or the inside
of the lid, as well as directly on the foodstuffs,
− the optimum temperature inside the insulated container, while maintaining certain constant external
parameters, is usually reached between 2 and 4 hours after the appliance has been in operation.
− the appliance is not designed to cool warm or hot foodstuffs.
• CLEANING AND MAINTENANCE
− Before carrying out any maintenance or repair work, switch off the appliance and disconnect
it from the power supply.
− Clean the housing, fittings and power cord with a soft, slightly dampened cloth with a little dishwashing
detergent.
WARNING: Do not immerse the appliance in water.
− Do not use any harsh cleaning agents for cleaning cause damage to the surface of the housing.
