15
Specifications
RANGE
Point-to-Point Up to 200m (656 ft) over OM3 or better multimode ber
USB DEVICE SUPPORT
Maximum Throughput 5 Gbps
Trac Types All Trac Types
Device Types All Device Types
Maximum Number of Devices and/or Hubs Up to 30 devices
LOCAL EXTENDER (LEX)
USB Connector 1 x USB 3.1 Gen 1 Type B Receptacle
Link Connector 1 x Duplex LC
Network Pass Through: 1 x RJ45
Dimensions 137.3mm x 232.1mm x 33.0mm (5.4” x 9.1” x 1.3”)
Enclosure Material Silver Anodized Aluminum
Power Supply 100-240V AC Input, 24V 1A DC Output
REMOTE EXTENDER (REX)
USB Connector 4 x USB 3.1 Gen 1 Type A Receptacles
Link Connector 1 x Duplex LC
Network Pass Through: 1 x RJ45
Dimensions 137.3mm x 232.1mm x 33.0mm (5.4” x 9.1” x 1.3”)
Enclosure Material Silver Anodized Aluminum
Available Current Up to 1.2 Amp (6W) to each USB port
Power Supply 100-240V AC Input, 24V 2.71A DC Output
ENVIRONMENTAL
Operating Temperature Range 0°C – 50°C (32°F – 122°F)
Storage Temperature Range -20°C – 70°C (-4°F – 158°F)
Operating Humidity 20% to 80% relative humidity, non-condensing
Storage Humidity 10% to 90% relative humidity, non-condensing
COMPLIANCE
EMC FCC (Class B), CE (Class B)
Environmental RoHS2 (CE)
SUPPORT
Warranty 2-year
