Installing the LEX Unit
1. Place the LEX unit near the computer.
2. Assemble the 24V 1A power adapter and country specic power cord together and connect them
into a suitable AC outlet.
3. Connect the supplied USB 3.1 Gen cable between the LEX host port and a USB 3 port on the host
computer.
Connecting the LEX to the REX
With Surface Cabling:
1. Plug one end of the CAT 6a/7 cable (not included) into the Link port on the LEX.
2. Plug the other end of the CAT 6a/7 cable into the Link port on the REX.
With Premise Cabling:
1. Plug one end of a CAT 6a/7 patch cord (not included) into the Link port on the LEX.
2. Plug the other end of the patch cord into the CAT 6a/7 information outlet near the host computer.
3. Plug one end of the second CAT 6a/7 patch cord (not included) into the Link port on the REX.
4. Plug the other end of the patch cord into the CAT 6a/7 information outlet near the USB device.
Do not exceed more than 10m total of patch cable when using premise cabling.
Installing the REX Unit
1. Place the REX near the USB device(s).
2. Assemble the 24V 2.71A power adapter and country specic power cord together and connect them
into a suitable AC outlet.
3. Connect the power adapter to the REX.
Checking the Installation
1. On the LEX and REX units, check that the Power, Status, Link, USB 2 and USB 3 LEDs are on. If
the Link LEDs are permanently o, then the cabling between the LEX and REX units may not
be installed properly or is defective.
2. For Windows users (7, 8, 8.1, 10), open Device Manager to conrm that the extender system has
been installed correctly. Expand the entry for Universal Serial Bus controllers by clicking the “+” sign.
If the extender system has been installed correctly, you should find two separate instances of
“Generic SuperSpeed USB Hub” listed.
To open Device Manager in Windows 7:
Open the Start Menu, right click on “Computer” then select: Manage >> Device Manager
To open Device Manager in Windows 8, 8.1 or 10:
Right click the Start Menu and then select: Device Manager
8
