BASIC OPERATION
■ Using the Main screen
There are 4 types of Main screens, AIS, AIS and Steering, AIS and Highway, and
Highway screen (only for watching).
In the AIS screen, the display range, the icons of the AIS target or waypoint, and GPS
data are displayed. You can change the display range and type, depending on your
operating style.
1. Push [DISP] several times to select the AIS screen.
2. Push [▲] or [▼] to select the desired display range.
• “Calculating” is displayed.
L See “DISPLAY RANGE” on page 12 for the
selectable display range.
3. Push [◄] or [►] to select an AIS target or waypoint.
• A target box is displayed around the selected target.
(p. 13)
• The selected target’s information is displayed in the
information box. (p. 12)
L The contents of the information box may dier,
depending on the selected target. (p. 15)
L See “Waypoint” on page 24 for details.
TIP:
• Push [►] to sequentially select each target that is
closest to your vessel.
• Push [◄] to sequentially select each target that is
farthest from your vessel.
4. Push [ENT] to display the Menu window.
• The Menu window is displayed.
5. Select “Details,” and then push [ENT] to display the
detail screen. (p. 19)
• The “DETAILS” screen is displayed.
NOTE: An alarm sounds when a malfunction occurs, an
AIS target is closer than the CPA and TCPA settings, and
so on, depending on the presetting. To stop the alarm
buzzer, push any key.
L If the popup screen is displayed, push any key again to
turn it OFF.
