1
BEFORE USING THE CONTROLLER
1-9
Feature description
■ Talkgroup Calls
Talkgroup Calls enables WLAN transceivers to select the group that belong to it from previously registered
groups in the IP1100CV.
When users select Talkgroup 01000, terminals are excluded from the original groups, as illustrated below.
• Talkgroup Calls require registering the Talkgroups in the [Destination Settings] screen and [ID List] screen. If the
“Talkgroup Type” in the [Destination Settings] screen is set to “Multiplex Talkgroup,” a WLAN transceiver can make a
Talkgroup Call between the linked Talkgroups.
(Transceiver Controller > Common Settings > ID List)
(Destination Settings > Destination Settings > Destination Settings > Talkgroup Type*)
*Displayed only when [Call Type] is set to “Talkgroup.”
• Set to the Controller whether All Call includes the Talkgroup or not, or the Talkgroup Call calls the IP100FS or not.
• The ID List and the destination settings set in the Controller are commonly used in each group that the WLAN transceiver
and IP100FS belong to.
Group 00100
All
Group 00101
Talkgroup 01000 Talkgroup 01001
00001 00002 00003 00004
00006 00007 00008 00009
Group 00100
All
Group 00101
Talkgroup 01000 Talkgroup 01001
00001 00002 00003
00007 00008
00004
00006
00009
When no Talkgroup is selected:
When a Talkgroup is selected:
